Hardware Type |
Indoor AP |
Number of Radios |
4 + 1 BLE |
Number of Antennas |
Internal
x4 2.4/5GHz Dual band WiFi + x4 6GHz band WiFi x2 Tri-band Scanning + 1 Single band 2.4GHz BLE/ ZigBee + 1GPS antenna |
External
x4 2.4/5GHz Dual band WiFi + x4 6GHz band WiFi x2 Tri-band Scanning + 1 Single band 2.4GHz BLE/ ZigBee + 1GPS antenna |
Antenna Type and Peak Gain |
Omni Directional Antenna
Dual band antenna: 4.0 dBi for 2.4GHz 5.6 dBi for 5 GHz
6GHz antenna: 5.4dBi for 6GHz band
Tri-band antenna: 4.0 dBi for 2.4 GHz, 6.0 dBi for 5 GHz and 5.7 dBi for 6 GHz band
BLE antenna: 5.1 dBi for 2.4GHz GPS active antenna: 2.2 dBi antenna |
Omni Directional Antenna
Dual band antenna: 5.0 dBi for 2.4GHz 5.0 dBi for 5 GHz
6GHz antenna: 5.8dBi for 6GHz band
Tri-band antenna: 5.0 dBi for 2.4 GHz, 5.0 dBi for 5 GHz and 4.0 dBi for 6 GHz band
BLE antenna: 5.1 dBi for 2.4GHz GPS active antenna: 2.2 dBi antenna |
Frequency Bands (GHz) |
. ISM 2.4-2.484 GHz · U-NII-1 5.15-5.25 GHz · U-NII-2A 5.25-5.35 GHz · U-NII-2C 5.47-5.725 GHz · U-NII-3 5.725-5.85 GHz · U-NII-4 5.850-5.925 GHz · U-NII-5 5.925–6.425 GHz · U-NII-6 6.425–6.525 GHz · U-NII-7 6.525–6.875 GHz · U-NII-8 6.875–7.125 GHz |
Radio 1 Capabilities |
Frequency band: 2.4GHz
Channel width: 20/40MHz
Modulation: BPSK, QPSK, 64/256/1024 QAM
MIMO Chains: 4×4 Service |
Radio 2 Capabilities |
Frequency band: 5.0GHz UNII-1 to UNII-4 Channel width: 20/40/80/160/240MHz Modulation: BPSK, QPSK, 64/256/1024/4096 QAM MIMO Chains: 4×4 Service |
Radio 3 Capabilities |
Frequency band: 6.0GHz UNII-5 to UNII-8 Channel width: 20/40/80/160/320MHz Modulation: BPSK, QPSK, 64/256/1024/4096 QAM MIMO Chains: 4×4 Service |
Radio 4 Capabilities |
Frequency band: 2.4/5.0/6.0GHz Channel width: 20/40/80/160MHz Modulation: BPSK, QPSK, 64/256/1024 QAM MIMO Chains: 2×2 Scanning |
Maximum Data Rate |
2.4GHz band: up to 1.148 Gbps
5.0GHz band: up to 8.648 Gbps
6.0GHz band: up to 11.530 Gbps |
Bluetooth Low Energy Radio |
Bluetooth scanning and iBeacon advertizement @10 dBm max TX power |
GNSS |
- Supported Bands
- Default constallations
- Number of Tracking Channels
- Number of Concurrent GNSS
- SBAS
- Sensitivity (@ Default Constallations)
|
- GPS L1 C/A, QZSS L1 C/A: 1575.42 MHz
- GLONASS L1: 1598.0625–1605.375 MHz
- BDS B1I : 1561.098 MHz, Galileo E1: 1575.42 MHz
- GPS + GLONASS + BDS + Galileo + QZSS
- 47
- 5
- WAAS, EGNOS, MSAS and GAGAN
- 147dBm
|
Interfaces |
x2 100M/1000M/2.5G/5.0G/10G Multigigabit Ethernet (RJ45)
x1 Type 3.0 USB at 4.5W
x1 RS-232 RJ45 Serial Port |
Power over Ethernet (PoE) |
x1 802.3bt PoE default or
x2 802.3at PoE (Dual PoE current sharing) |
Simultaneous SSIDs |
Up to 24 |
EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST |
User/Device Authentication |
WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blacklist and whitelist |
Maximum Tx Power (Conducted) |
2.4GHz band: 29 dBm / 794 mW (4 chains combined)
5.0GHz band: 27.8 dBm / 602 mW (4 chains combined)
6.0GHz band: 23 dBm / 200 mW (4 chains combined @ 160MHz BW) |
Kensington Lock |
Yes |
Yes |
IEEE Standards |
802.11a, 802.11b, 802.11be, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.11ax, 802.1X, 802.3ad, 802.3at, 802.3bt, 802.3az |
SSIDs Supported |
Local-Bridge, Tunnel, and Mesh |
Per Radio Client Capacity |
Up to 512 clients per radio (Radio1, Radio2 and Radio3) |
Cellular Co-existence |
Yes |
LED Off Mode |
Yes |
OFDMA |
Yes (UL and DL) |
Spatial Reuse (BSS Coloring) |
Yes |
UL MU-MIMO |
Yes |
DL-MU-MIMO |
Yes |
Enhanced Target Wake Time (TWT) |
Yes |
ZeroWait DFS |
No |
Rogue Scan radio modes |
Background, Dedicated |
WIPS / WIDS radio modes |
Background, Dedicated (recommended) |
Packet Sniffer Mode |
Yes |
Spectrum Analyzer |
Yes |
Length x Width x Height |
9.84 x 9.84 x 2.26 inches (250 x 250 x 57.5 mm) |
Weight |
4.36 lbs (1.98 kg) |
Package (shipping) Weight |
6.9 lbs (3.13 kg) |
Mounting Options |
Ceiling, T-Rail, and Wall |
Included Accessories |
Standard Mounting Kit for Ceiling, T-Rail, and Wall |
Power Supply |
GPI-145 or SP-FAP250-PA-10 |
Power Consumption (Maximum) |
41.7 W |
PoE Mode |
802.3at : R1(2.4Ghz) and R2(5 GHz) operation in Low Tx Power 17dBm ; Chain 4×4; USB – Disabled 802.3bt / DC : Full – Tx Power Full ; Chain 4×4; USBEnabled |
Humidity |
5% – 90% non condensing |
Operating / Storage Temperature |
32°F to 122°F (0°C to 50°C) / -22°F to 158°F (-30°C to 70°C) |
Directives |
Low Voltage Directive • RoHS |
UL2043 Plenum Material |
Yes |
Mean Time Between Failures |
> 10 Years |
IP Rating |
N/A |
Surge Protection Built In |
Yes |
Hit-less PoE Failover |
N/A |
WiFi Alliance Certified |
Certified (Wi-Fi 7 in progress) |
DFS |
No |
Limited Lifetime Warranty |
Yes |
