Synology Expansion Unit ​RX1217RP

Compara

Our compact 2U, 8-bay rackmount for small- and medium-sized businesses.

Pretul afisat contine TVA (19%).

12.481,42 lei

Compara

Volume expansion & backup

When drive capacity is running low on a Synology RackStation, Synology RX1217/RX1217RP offers an easy way to immediately expand storage by providing 12 additional drive slots. The RAID volume on the Synology RackStation can be expanded directly without having to reformat the existing hard drives, ensuring service continuity during the expansion process. To ensure 24/7 service uptime, Synology RX1217RP is equipped with redundant power supplies, allowing automatic failover support if one of the PSUs fail.

When created as a separate volume, Synology RX1217/RX1217RP also serves as an additional local backup destination for Synology RackStations.

Reliable plug-and-use design

Synology RX1217/RX1217RP securely connects to Synology RackStation servers with a high-bandwidth expansion cable, ensuring maximum data throughput and smooth operation — as if they are part of the internal drives of Synology RackStation. SATA 6Gb/s interface ensures the installed drives provide high quality, outstanding data processing performance.

Green & easy to manage

Hibernation mode can be manually configured to start automatically when the system has been inactive for a period of time. This not only saves energy but also extends the lifespan of hard drives. RX1217/RX1217RP will also smartly power on/off with the attached RackStation, so no user intervention is needed to keep this system running smartly and efficiently.

SKU: ​RX1217RP Categorii: , ,
Hardware Specifications
Applied Models
 Supports creating volumes across different units
  • 21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+
  • 19 series:RS1619xs+
  • 18 series:RS3618xs, RS2818RP+, RS2418RP+, RS2418+
  • 17 series:RS4017xs+, RS3617xs+, RS3617RPxs, RS3617xs
  • 16 series:RS2416RP+, RS2416+
  • 14 series:RS3614xs+, RS3614RPxs, RS3614xs, RS2414RP+, RS2414+
  • 13 series:RS3413xs+
  • 12 series:RS3412RPxs, RS3412xs, RS2212RP+, RS2212+
  • 11 series:RS3411RPxs, RS3411xs, RS2211RP+, RS2211+
Notes
  • To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.
  • DSM version requirement: 6.0.1-7393 or later version
Storage
 Drive Bays 12
Compatible Drive Type*
  • 3.5″ SATA HDD
  • 2.5″ SATA HDD
  • 2.5″ SATA SSD
Maximum Internal Raw Capacity 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Hot Swappable Drive*
RAID Management through Synology DSM
Notes Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.
External Ports
 Expansion Port 1
Appearance
 Size (Height x Width x Depth) 88 mm x 430.5 mm x 664 mm
88 mm x 430.5 mm x 692 mm (for RP model)
Size (Height x Width x Depth) (with server ears) 88 mm x 482 mm x 696 mm
88 mm x 482 mm x 724 mm (for RP model)
Weight 12.7 kg
13.4 kg (for RP model)
Rack Installation Support* 4-post 19″ rack (Synology Rail Kit – RKS-02)
Notes The rail kit is sold separately
Power
 Power Recovery Synchronized with the Synology RackStation
Power Supply Unit / Adapter 500 W
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 68.60 W (Access)
27.45 W (HDD Hibernation)
71.3 W (Access) (for RP model)
31.2 W (HDD Hibernation) (for RP model)
British Thermal Unit 234.23 BTU/hr (Access)
93.73 BTU/hr (HDD Hibernation)
243.52 BTU/hr (Access) (for RP model)
106.53 BTU/hr (HDD Hibernation) (for RP model)
Redundant Power Supply (for RP model)
Notes Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
Temperature
 Operating Temperature 5°C to 35°C (40°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Others
 System Fan 80 mm x 80 mm x 3 pcs
Easy Replacement System Fan
Noise Level* 54.6 dB(A)
54.2 dB(A) (for RP model)
Notes Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Certification
  • FCC
  • CE
  • BSMI
  • EAC
  • RCM
  • KC
Warranty
 5 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt.
Environment & Packaging
Environment
 RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 1
  • AC Power Cord X 2 (for RP model)
  • Expansion Cable: Infiniband X 1
  • Quick Installation Guide X 1
Optional Accessories
  • 3.5″ SATA HDD: HAT5300
  • 2.5″ SATA SSD: SAT5210
  • Rail Kit Sliding: RKS-02
