SYN 65 Inch BOE 4K DP Daisy Chain 2×2 LCD Video Wall With Matrix
digital signage equipment
Compara
SYN 65 Inch BOE 4K DP Daisy Chain 2×2 LCD Video Wall With Matrix
| Key Word: | DP Daisy Chain 4K LCD Video Wall | Panel Brand: | BOE Original LCD Video Wall Panel |
|---|---|---|---|
| Screen Size: | 65 Inch | Narrow Bezel: | 3.5mm Seamless LCD Video Wall |
| Resolution: | 3840*2160 | Port: | HDMI In*1, DVI In*1, VGA In*1, DP*1, RS232 In*1, RS232 Out*2 |
| Insllation: | Wall Mount, Pop-out Bracket, Floorstanding Bracket Or Cabinet | Daisy Chain: | Support |
| Certificate: | CE, FCC, ROHS, CCC, RCM | Delivery Time: | One Week |
| High Light: | 2×2 LCD Video Wall,
BOE LCD Video Wall, BOE 4K Digital Signage Video Wall |
||
Product Description
65 Inch BOE 4K DP Daisy Chain 2X2 LCD Video Wall Full Screen Digital Sinage with Matrix
Quick details of digital signage big screen wall :
1. 65inch BOE original panel, A level.
2. 3840*2160 4K resolution.
3. With DP daisy chain port which also support 4K signal input.
4. Various installation: 2×2, 3×3, 4×4, 2×3, 3×4 etc.
5. Full screen displaying, each screen can display different picture, if need picture in picture, we have processor on your choice.
6. Can be installed on the wall with standard bracket or pop-out bracket, also we have floorstanding bracket or cabinet.
7. Has Android or Windows player box for signal input and has free remote control software.
Description of digital signage big screen wall :
Genevision has various LCD video wall, screen size can be 46inch, 49inch, 55inch and 65inch, hotsale brand is BOE and LG panel, resolution can be 2K or 4K, seamless bezel can be 3.5mm or 1.7mm, high brightness can be in 500nits and 700nits, different screen and brand has different price, also price is changing every several days, suggest contact us for details for any specific project.
This 65inch has 4K resolution screen, also motherboard has DP daisy chain port which support 4K signal input, with a splitter, it can provide a full screen displaying solution, if with a matrix, splitting screen displaying fucntion is supported as well, if picture and picture featuer is also needed, we will use a processor to meet the request. We’re one-stop provider, all spare parts included can be supplied and sent in one package.
Besides, each screen has 1pc HDMI cable, 1pc RS232 cable and 1pc power cable for free, so for 2*2 installation, no need to buy extra cables, for other installation, we will recommend what length cable you need to buy extra, you also can buy them locally.
Support various installation models: wall mount, floorstanding bracket, floorstanding cabinet.
Specification of digital signage big screen wall :
| Specification | MAD-650 | Panel Size | 65″LED screen | ||
| Panel brand | Original BOE A level | ||||
| Aspect Ratio | 16:9 | ||||
| Visual Angle | Horizontal 178/Vertical178 | ||||
| Brightness | 500cd/sqm | ||||
| Bezel | 3.5 mm | ||||
| Back light | LED backlight | ||||
| Contract Ratio | 1200:1 | ||||
| Resolution Ratio | 3840*2160 | ||||
| Color Components | 16.7M | ||||
| Response Time | 8ms | ||||
| Power Consumption | 120W/150W | ||||
| Standby power consumption | 10W | ||||
| Power Supply | Input:AC110-220V-50/60Hz | ||||
| Life of Panel | 60000Hours | ||||
| Panel Display Area | 1209.6(W)×680.4(H) mm | ||||
| Outline Dimension | 1211.54(W)×682.34(H)×118.5mm | ||||
| Port | Input: HDMI in*1,VGA*1,DVI*1,RS-232 in*1, RS232 out*2, DP*1 | ||||
| VGA/DVI Resolution Ratio | 640*480,800*600,1024*768,1280*1024,1600*1200,1920*1080 | ||||
| Resolution Ratio | 480I,480P,576I,720P,1080I,1080P | ||||
| Split Screen/PIP Mode | Two signals image or PIP | ||||
| Splice Function | Multiscreen Splice Function(image processing Function) | ||||
| Carton Packing | 2pc/carton, carton size: 135*34*81cm, G.W.: 58kg | ||||
| Wooden box packing | 7pc/wooden box, wooden box size: 140*128*98cm, G.W.:281kg | ||||
| Bracket carton packing(for 7pc system) | 146*34*25cm, G.W.: 33kg | ||||
Also, we have other brand of LCD video wall as below for your option :
| MD-DV460FHMNV0 | DV460FHM-NV0 | BOE | 500nits | 46寸3.5MM | ||
| MD-DV490FHMNV4 | DV490FHM-NV4 | BOE | 500nits | 49寸3.5MM | ||
| MD-DV550FHMNV8 | DV550FHM-NV8 | BOE | 500nits | 55寸3.5MM | ||
| MD-DV550FHMNVD | DV550FHM-NVD | BOE | 500nits | 55寸0.88MM | ||
| MD-DV650QUMNV0 | DV650QUM-NV0 | BOE | 500nits | 65寸3.5MM 4K | ||
| MD-DV550FHZNVF | DV550FHM-NVF | BOE | 500nits | 55寸3.5MM | ||
| MD-DV550FHMNV9 | DV550FHM-NV9 | BOE | 500nits | 55寸1.7MM | ||
| MD-DV460FHMNV3 | DV460FHM-NV3 | BOE | 500nits | 46寸1.7MM | ||
| MD-DV460FHMNV2 | DV460FHM-NV2 | BOE | 500nits | 46寸0.88MM | ||
| MD-LD490DUNZMA1 | LD490DUN-ZMA1 | LG | 500nits | 49寸3.5MM | ||
| MD-LD550DUNTGB5 | LD550DUN-TGB5 | LG | 500nits | 55寸3.5MM | ||
| MD-LD550DUNTHB8 | LD550DUN-THB8 | LG | 500nits | 55寸1.8MM | ||
| MD-LD550DUNTMA2 | LD550DUN-TMA2 | LG | 500nits | 55寸 0.88MM | ||
| MD-LD550DUNTHA8 | LD550DUN-THA8 | LG | 700nits | 55寸1.8MM | ||
| MD-LD550DUNTMA3 | LD550DUN-TMA3 | LG | 700nits | 55寸 0.88MM | ||
| MD-SS550HJ1S02 | SS550HJ1-S02 | Innolux | 500nits | 55寸3.5MM | ||
| MD-MG5461B011 | MG5461B01-1 | 500nits | 55寸3.5MM | |||
| MD-P550HVN08.2 | P550HVN08.2 | AUO | 500nits | 46寸1.8MM |
Application of digital signage big screen wall :
LCD screen wall can be used in TV studio, Exbition and Office, also indoor LCD wall screen can be applied in start hotel, Library, Museum and Cinema.
